SCM Minimax CU 410E

Product Specifications

• Blade diameter, max.

  315 mm

• Cutting depth, max.

  100 mm

• Blade tilt

  0 - 45°

• Cast iron table size

  1250 x 430 mm

• Squaring stroke, max.

  1600 mm

• Rip fence capacity

  1050 mm

• Rip fence adjustment

  Manual

• Tool diameter, max.

  210 mm

• Tool diameter lowered under table, max.

  240 mm

• Useful spindle length, max.

  125 mm

• Spindle diameter

  30 mm

• Spindle speeds

  3500/ 6000/ 8000/ 10000 rpm

• Surfacing width capacity

  410 mm

• Thicknessing depth, min. - max.

  3 - 230 mm

• Cutting depth infeed table adjustment

  0 - 5 mm

• Surfacing table length, overall

  2000 mm

• Thicknessing table length

  775 mm

• Cutterblock diameter

  87 mm

• Cutterblock type

  High Speed Steel (HSS)

• Number of knives

  3

• Feed speed(s)

  6 & 12 m/min

• Fence tilt

  0 - 45°

• Extraction outlet(s)

  3 x 120 mm

• Motor

  3 x 4 kW (5.5 HP)

• Power

  3 phase
